Description
Full Band Directional Log Antenna (11 dBi) gain.Dimensions: 13″x8.5″x2.5″. N Female connector. Rated wind velocity km/h 216. Bandwidth: 70MHz. Weighs 2.5 lbs. Can be used with cell service in the 806-960/1710-2500MHz band. Maximum Power: 200W.
Technical specs.
Frequency Range –MHz800~960 /1710~2500
Gain –dBi 9.5 / 11
Polarization in Vertical Plane -°60/50
Polarization in Horizontal Plane -°80/60
VSWR – ≤1.5
Front-to-back Ratio -dB – ≥ 20
Nominal Impedance –Ω – 50
Polarization -Vertical
Max Power –W -100
Connector -N-Female
Mast Mount Diameter –mm 40 – 50
Antenna Dimension-mm 330 x 215 x 65
Weight -kg 1.1
