Multiplexer – MUX

$399.00

  • A multiplexer performs the function of selecting the input on any one of ‘n’ input lines and feeding this input to one output line. Multiplexers are used as one method of reducing the number of integrated circuit packages required by a particular circuit design. This in turn reduces the cost of the system.
Categories: , , ,

Description

Technical specifications

Type: Multiplexer: RX: 869-896MHz/1935-1990MHz TX: 824-849MHz/1850-1910MHz – N-Female/2 SMA Female(Tx&Rx)

BAND RANGE-

RX: 869-896MHz & 1935-1990MHz

TX: 824-849MHz & 1850-1910MHz

PASSBAND intersection loss: <1.5dB

VSWR: <1.3

ATTENUATION: >75dB – Between RX&TX

POWER: <30W(CW)

N-female(ANT)

SMA- female(Tx&Rx)

Additional information

Weight 5 lbs
