Description
The repeaters have been pre-loaded with the most popular Cellular and PCS band combinations from across the United States. If your particular band combination is not pre-loaded, Westell will email you the proper file to download into the BDA, usually within 24-48 hours after contact. The Westell-DSP85-250-C/P is a rack or wall mountable digital repeater with 85db of gain and 27dBm composite output power. This version has a single input and a single output.
Tech Specs:
| Tuning Method | Field selectable |
| Frequency Range | 824-896 MHz / 1850-1990 MHz |
| Gain | 85 dB |
| Bands Supported | 850 CELL / 1900 PCS |
| Composite Power Uplink | 27 dBm |
| RF Connectors | N Female |
| Composite Power Downlink | 27 dBm |
| Gain Adjustment Range (dB +/-) | 0 to 30 in 0.5dB steps |
| Gain Control | Manual & AGC |
| Noise Figure (U/L, D/L) | 6dB |
| Single/Dual Inputs | Single |
| Single/Dual/Quad Outputs | Single |
| Item Width | 18 in |
| Item Height | 3.4 in |
| Item Length | 19 in |
| Item Weight | 35 lb |
| Mfg. Warranty | 2 Years |
